Fujitsu SCANSNAP iX1400 User Manual

Pad Assy
ADF Top Section
Pad Plate
ATTENTION
Attach the pad assy with the front side up.
If the pad assy is attached upside down, paper jams or other feeding errors may occur.
Correct Incorrect
Front Back
6. Make sure that the pad assy is attached to the retaining hook firmly.
ATTENTION
Make sure that the pad assy is attached firmly. Otherwise, paper jams or other feeding errors
may occur.
7. Close the ADF top section.
ADF Paper Chute (Cover)
ADF Top Section
→ It clicks when it returns to its original position.
8. Connect the power connection cable (power cable or USB bus power cable)
to the power supply source (AC outlet or computer), and turn on the
ScanSnap.
9. Reset the pad assy count.
Replacing Consumables for S1300i
487

Fujitsu SCANSNAP iX1400 Specifications

General

Scanner type	ADF scanner
Product color	Black
Built-in display	No
Color scanning	Yes
Maximum scan size	216 x 360 mm
ADF scan speed (b/w, A4)	600 ppm
Optical scanning resolution	600 x 600 DPI
Minimum scan area (Flatbed)	50.8 x 50.8 mm
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Scanning media types supported	Business Card, Post Card(JPN)
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	0 - 80 g/m²
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
USB connector type	USB Type-B
Input voltage	100 - 240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Sensor type	Colour CIS
Scan drivers	ISIS, ScanSnap, TWAIN
Scan file formats	JPG, PDF
Daily duty cycle (max)	- pages
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Standard input capacity	50 sheets
Sustainability certificates	ENERGY STAR, RoHS
Certification	CE, RoHS
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	161 mm
Width	292 mm
Height	152 mm
Weight	3200 g
