Fujitsu SCANSNAP iX1400 User Manual

No. Name Description
7 [Scan] button (*1) Starts scanning. Can be pressed even when the stacker is closed.
Indicates the status of the ScanSnap as follows:
Blue (lit): Ready
Blue (flashing): Scanning
Orange (flashing): Error
8 Stacker Pull it out to use it.
Stacks up the ejected documents.
9 Receipt Guide Attach it to the ADF paper chute (cover) for it to be used.
If you use the Receipt Guide, you can place documents with different
widths such as receipts in it to scan them at the same time.
*1: When the ScanSnap has turned off automatically because of the automatic power off function,
perform the following to turn the ScanSnap back on.
l iX1600/iX1500
Press the touch panel, or close the ADF paper chute (cover) and open it again
l iX1400
Press the [Scan] button (this will not start scanning), or close the ADF paper chute (cover)
and open it again
For details, refer to "Automatic Power OFF (iX1600 / iX1500 / iX1400 / iX500 / iX100 / SV600 /
S1300i)" (page 100).
Back
10
11
12
13
No. Name Description
10 USB connector Slide the cover of the USB connector up to open it and then connect
the USB cable to the USB connector.
The cover of the USB connector slides up either one or two levels.
Open the cover according to the type of the USB cable you have.
l First level: USB 2.0 cable
l Second level: USB 3.0 cable
11 Power connector Used to connect a power cable.
12 Security cable slot Used to connect an anti-theft security cable (commercially available).
13 Ventilation port Holes for ventilating hot air from inside the ScanSnap.
Parts and Functions
70

Fujitsu SCANSNAP iX1400 Specifications

General

Scanner type	ADF scanner
Product color	Black
Built-in display	No
Color scanning	Yes
Maximum scan size	216 x 360 mm
ADF scan speed (b/w, A4)	600 ppm
Optical scanning resolution	600 x 600 DPI
Minimum scan area (Flatbed)	50.8 x 50.8 mm
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Scanning media types supported	Business Card, Post Card(JPN)
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	0 - 80 g/m²
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
USB connector type	USB Type-B
Input voltage	100 - 240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Sensor type	Colour CIS
Scan drivers	ISIS, ScanSnap, TWAIN
Scan file formats	JPG, PDF
Daily duty cycle (max)	- pages
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Standard input capacity	50 sheets
Sustainability certificates	ENERGY STAR, RoHS
Certification	CE, RoHS
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	161 mm
Width	292 mm
Height	152 mm
Weight	3200 g
