Attaching the Receipt Guide (iX1600 / iX1500 /
iX1400)
When you scan business cards or receipts, attaching the Receipt Guide to the ScanSnap makes it
easy to scan them. By using the Receipt Guide for business cards and receipts, you can place
documents with different widths such as receipts in it to scan them at the same time.
Documents that can be scanned with the Receipt Guide
The Receipt Guide allows you to load three kinds of documents. It allows you to load different-sized
documents in each loading section to scan them at the same time.
In addition, you can move side guides, or close the ADF paper chute (cover) to turn the power off
with the Receipt Guide attached to the ScanSnap. Therefore, you do not need to attach and remove
the Receipt Guide every time you use it.
HINT
Attaching the Receipt Guide on the ScanSnap limits the number of sheets that can be loaded in the
ADF paper chute (cover). Remove the Receipt Guide from the ScanSnap when scanning a large
number of documents.
1
2
3
Example: iX1600
Loading
section
1 2 3
Document type Business cards and receipts Receipts Office paper
Paper weight
40 to 209 g/m
2
(11 to 56 lb)
Paper size
Width
58 mm (2.28 in.)
Length
50.8 to 360 mm (2 to 14.17 in.)
For long page documents, up
to 863 mm (34 in.)
Width
83 mm (3.26 in.)
Length
50.8 to 360 mm (2 to 14.17 in.)
For long page documents, up
to 863 mm (34 in.)
Width
148 to 216 mm (5.82 to 8.5 in.)
Length
50.8 to 360 mm (2 to 14.17 in.)
For long page documents, up
to 863 mm (34 in.)
Attaching the Receipt Guide (iX1600 / iX1500 / iX1400)
111

Table of Contents

Other manuals for Fujitsu ScanSnap iX1500

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Fujitsu ScanSnap iX1500 and is the answer not in the manual?

Fujitsu ScanSnap iX1500 Specifications

General IconGeneral
Color scanningYes
Maximum scan size216 x 3000 mm
ADF scan speed (color, A4)30 ppm
Optical scanning resolution600 x 600 DPI
Black/white scanning color modesGrayscale, Monochrome
DisplayTFT
Scanner typeADF + Manual feed scanner
Product colorWhite
Display diagonal4.3 \
Scan toCloud
Sensor typeDual CIS
Scan driversScanSnap
Daily duty cycle (max)- pages
Auto document feeder (ADF) input capacity50 sheets
Maximum scan length3000 mm
Card thickness (max)0.76 mm
ISO A-series sizes (A0...A9)A3, A4
ISO B-series sizes (B0...B9)B4
Scanning media types supportedPlain paper
Maximum ISO A-series paper sizeA3
Cables includedAC, USB
PC connectionUSB 3.2 Gen 1 (3.1 Gen 1)
Sustainability certificatesRoHS, ENERGY STAR
Operating temperature (T-T)5 - 35 °C
Operating relative humidity (H-H)20 - 80 %
Mac operating systems supportedMac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms64-bit WEP, 128-bit WEP, WPA, WPA-AES, WPA-TKIP, WPA2, WPA2-AES, WPA2-PSK, WPA2-TKIP
Input voltage100 - 240 V
Power supply typeAC
AC input frequency50 - 60 Hz
Power consumption (sleep)1.6 W
Power consumption (typical)17 W
USB version3.2 Gen 2 (3.1 Gen 2)
Frequency band2.4/5 GHz GHz
USB connector typeUSB Type-B
Standard interfacesUSB 1.1, USB 2.0, USB 3.2 Gen 1 (3.1 Gen 1), Wireless LAN
Harmonized System (HS) code84716070
Weight and Dimensions IconWeight and Dimensions
Depth161 mm
Width292 mm
Height152 mm
Weight3400 g
