Connecting the ScanSnap to a Computer Directly in Direct
Connect Mode (iX100)
You can use the ScanSnap Wireless Setup Tool Wizard to complete the preparation for connecting
the ScanSnap to a computer.
For details, refer to "Connecting the ScanSnap to a Wireless LAN (iX500 / iX100)" (page 131).
The following explains how to connect the ScanSnap and a computer when the computer to be
connected has already been registered by using the ScanSnap Wireless Setup Tool Wizard.
1. Click
in the notification area located at the far right of the taskbar, and
connect the ScanSnap network displayed in the wireless network list.
The ScanSnap network name (SSID) and the security key are printed on the label attached to
the bottom of the scanner.
HINT
The network name (SSID) and the security key can be checked or changed with the ScanSnap
Wireless Setup Tool.
2. Disconnect the USB cable connecting the ScanSnap to the computer.
ATTENTION
If the ScanSnap Manager icon is , exit ScanSnap Connect Application on the mobile
device.
a The ScanSnap is automatically connected to the computer via wireless LAN and the
ScanSnap Manager icon changes to
.
If the icon does not change, go to step 3.
HINT
l If the [Connect automatically to previous ScanSnap by Wi-Fi] checkbox is selected and the
previously connected ScanSnap is available for the connection, the computer is connected to
the ScanSnap automatically.
l The computer can be connected to only one ScanSnap.
l Only one computer can be connected to the ScanSnap via wireless LAN.
l When you automatically connect a computer and the ScanSnap that had been connected via
wireless LAN before, if the password for the ScanSnap to be connected is changed, a
notification informs you of the status.
3. Right-click the ScanSnap Manager icon
in the notification area located
at the far right of the taskbar and select [Connect by Wi-Fi] from the "Right-
Click Menu" (page 87).
a The [ScanSnap Manager - Connect by Wi-Fi] window appears.
Connecting the ScanSnap to a computer or mobile device via Wireless LAN (iX100)
140

Fujitsu ScanSnap iX1500 Specifications

General

Color scanning	Yes
Maximum scan size	216 x 3000 mm
ADF scan speed (color, A4)	30 ppm
Optical scanning resolution	600 x 600 DPI
Black/white scanning color modes	Grayscale, Monochrome
Display	TFT
Scanner type	ADF + Manual feed scanner
Product color	White
Display diagonal	4.3 \
Scan to	Cloud
Sensor type	Dual CIS
Scan drivers	ScanSnap
Daily duty cycle (max)	- pages
Auto document feeder (ADF) input capacity	50 sheets
Maximum scan length	3000 mm
Card thickness (max)	0.76 mm
ISO A-series sizes (A0...A9)	A3, A4
ISO B-series sizes (B0...B9)	B4
Scanning media types supported	Plain paper
Maximum ISO A-series paper size	A3
Cables included	AC, USB
PC connection	USB 3.2 Gen 1 (3.1 Gen 1)
Sustainability certificates	RoHS, ENERGY STAR
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Mac operating systems supported	Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-AES, WPA-TKIP, WPA2, WPA2-AES, WPA2-PSK, WPA2-TKIP
Input voltage	100 - 240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Power consumption (sleep)	1.6 W
Power consumption (typical)	17 W
USB version	3.2 Gen 2 (3.1 Gen 2)
Frequency band	2.4/5 GHz GHz
USB connector type	USB Type-B
Standard interfaces	USB 1.1, USB 2.0, USB 3.2 Gen 1 (3.1 Gen 1), Wireless LAN
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	161 mm
Width	292 mm
Height	152 mm
Weight	3400 g
