Fujitsu ScanSnap iX1500 User Manual

Scanning Documents (iX500)
You can load documents such as handouts for meetings or business cards directly in the ScanSnap
for scanning.
For details about documents that can be scanned, refer to "Documents to Scan (iX500)" (page 212).
1. If you are loading multiple sheets, check the number of sheets.
The maximum number of sheets in the ScanSnap is as follows:
For A4 or smaller sizes: Up to 50 sheets can be loaded (with paper weight of 80 g/m
2
[20 lb]
and thickness of the document stack under 5 mm [0.2 in.]).
ATTENTION
If you try to scan more than the maximum amount that can be loaded, the following problems
may occur:
l Files cannot be properly created due to excessive file size.
l Paper jams occur during scanning.
2. Fan the documents.
1. Hold both ends of the documents and fan them a few times.
2. Rotate the documents 90 degrees and fan them in the same manner.
3.
Straighten the edges of the documents and slightly displace the top edges at
an angle.
At an Angle
Feed Direction
ATTENTION
Paper jams or damage to documents may occur if you scan the documents without aligning the
edges first.
Scanning Documents with iX500
216

Fujitsu ScanSnap iX1500 Specifications

General

Color scanning	Yes
Maximum scan size	216 x 3000 mm
ADF scan speed (color, A4)	30 ppm
Optical scanning resolution	600 x 600 DPI
Black/white scanning color modes	Grayscale, Monochrome
Display	TFT
Scanner type	ADF + Manual feed scanner
Product color	White
Display diagonal	4.3 \
Scan to	Cloud
Sensor type	Dual CIS
Scan drivers	ScanSnap
Daily duty cycle (max)	- pages
Auto document feeder (ADF) input capacity	50 sheets
Maximum scan length	3000 mm
Card thickness (max)	0.76 mm
ISO A-series sizes (A0...A9)	A3, A4
ISO B-series sizes (B0...B9)	B4
Scanning media types supported	Plain paper
Maximum ISO A-series paper size	A3
Cables included	AC, USB
PC connection	USB 3.2 Gen 1 (3.1 Gen 1)
Sustainability certificates	RoHS, ENERGY STAR
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Mac operating systems supported	Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-AES, WPA-TKIP, WPA2, WPA2-AES, WPA2-PSK, WPA2-TKIP
Input voltage	100 - 240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Power consumption (sleep)	1.6 W
Power consumption (typical)	17 W
USB version	3.2 Gen 2 (3.1 Gen 2)
Frequency band	2.4/5 GHz GHz
USB connector type	USB Type-B
Standard interfaces	USB 1.1, USB 2.0, USB 3.2 Gen 1 (3.1 Gen 1), Wireless LAN
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	161 mm
Width	292 mm
Height	152 mm
Weight	3400 g
