Connecting the ScanSnap via Wireless LAN
(iX500/iX100)
By connecting the ScanSnap to a computer or a mobile device via wireless LAN, you can scan
documents.
iX100
Select one of the following wireless modes to connect the ScanSnap to the computer or mobile
device.
l Access Point Connect mode
When a wireless LAN environment has already been configured, the ScanSnap and the
computer or mobile device are connected via a wireless access point.
l Direct Connect mode
When a wireless LAN environment has not been configured or the ScanSnap cannot establish a
connection to a wireless access point, the ScanSnap and the computer or mobile device are
connected directly via wireless LAN.
The wireless mode automatically switches to the mode in accordance with the wireless LAN
environment in which the ScanSnap is used.
When the ScanSnap is turned on, it is connected to the wireless access point that was set in the
ScanSnap Wireless Setup Tool. If no wireless access point is detected, the mode is switched to the
Direct Connect mode.
HINT
l When the wireless access point that was set in the ScanSnap Wireless Setup Tool is detected,
even if the wireless access point is not connectable, the mode is not switched from the Access
Point Connect mode to the Direct Connect mode.
To switch the mode to the Direct Connect mode, turn off the ScanSnap and then turn it on again in
an environment in which no wireless access point is detected.
l Even if the wireless access point that was set in the ScanSnap Wireless Setup Tool is detected
after the mode is switched to the Direct Connect mode, the mode is still not switched to the Access
Point Connect mode.
To connect the ScanSnap in Access Point Connect mode, turn off the ScanSnap and then turn it on
again.
For details about how to switch the wireless mode and how to configure the wireless settings, refer
to the ScanSnap Wireless Setup Tool Help.
l "Preparations for Connecting the ScanSnap via Wireless LAN (iX500 / iX100)" (page 130)
l "Connecting the ScanSnap to a Wireless LAN (iX500 / iX100)" (page 131)
l "Connecting the ScanSnap to a Computer or Mobile Device via Wireless LAN (iX500)" (page
132)
l "Connecting the ScanSnap to a computer or mobile device via Wireless LAN (iX100)" (page
136)
l "Reconnecting to a Wireless Access Point Using the ScanSnap WPS Button (iX500 / iX100)"
(page 143)
Connecting the ScanSnap via Wireless LAN (iX500/iX100)
129

Fujitsu ScanSnap iX1500 Specifications

General

Color scanning	Yes
Maximum scan size	216 x 3000 mm
ADF scan speed (color, A4)	30 ppm
Optical scanning resolution	600 x 600 DPI
Black/white scanning color modes	Grayscale, Monochrome
Display	TFT
Scanner type	ADF + Manual feed scanner
Product color	White
Display diagonal	4.3 \
Scan to	Cloud
Sensor type	Dual CIS
Scan drivers	ScanSnap
Daily duty cycle (max)	- pages
Auto document feeder (ADF) input capacity	50 sheets
Maximum scan length	3000 mm
Card thickness (max)	0.76 mm
ISO A-series sizes (A0...A9)	A3, A4
ISO B-series sizes (B0...B9)	B4
Scanning media types supported	Plain paper
Maximum ISO A-series paper size	A3
Cables included	AC, USB
PC connection	USB 3.2 Gen 1 (3.1 Gen 1)
Sustainability certificates	RoHS, ENERGY STAR
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Mac operating systems supported	Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-AES, WPA-TKIP, WPA2, WPA2-AES, WPA2-PSK, WPA2-TKIP
Input voltage	100 - 240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Power consumption (sleep)	1.6 W
Power consumption (typical)	17 W
USB version	3.2 Gen 2 (3.1 Gen 2)
Frequency band	2.4/5 GHz GHz
USB connector type	USB Type-B
Standard interfaces	USB 1.1, USB 2.0, USB 3.2 Gen 1 (3.1 Gen 1), Wireless LAN
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	161 mm
Width	292 mm
Height	152 mm
Weight	3400 g
