Side Guide
ATTENTION
When the [Place document face up] checkbox is selected in the [Scanning mode option] window,
load the documents face-up and bottom edge down.
To open the [Scanning mode option] window, click the [Option] button in the [Scanning] tab of the
"ScanSnap Setup Window" (page 89).
7. Adjust the side guides to the width of the documents.
Hold each side guide in the middle to adjust them. Otherwise, the documents may be fed
skewed.
Documents
8. Press the [Scan] button on the ScanSnap to start a scan.
ATTENTION
Do not perform the following operations during scanning. Doing so will stop scanning.
l Connect or disconnect the ScanSnap and other USB devices.
Scanning Documents with S1300i
303

Table of Contents

Other manuals for Fujitsu ScanSnap iX1500

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Fujitsu ScanSnap iX1500 and is the answer not in the manual?

Fujitsu ScanSnap iX1500 Specifications

General IconGeneral
Color scanningYes
Maximum scan size216 x 3000 mm
ADF scan speed (color, A4)30 ppm
Optical scanning resolution600 x 600 DPI
Black/white scanning color modesGrayscale, Monochrome
DisplayTFT
Scanner typeADF + Manual feed scanner
Product colorWhite
Display diagonal4.3 \
Scan toCloud
Sensor typeDual CIS
Scan driversScanSnap
Daily duty cycle (max)- pages
Auto document feeder (ADF) input capacity50 sheets
Maximum scan length3000 mm
Card thickness (max)0.76 mm
ISO A-series sizes (A0...A9)A3, A4
ISO B-series sizes (B0...B9)B4
Scanning media types supportedPlain paper
Maximum ISO A-series paper sizeA3
Cables includedAC, USB
PC connectionUSB 3.2 Gen 1 (3.1 Gen 1)
Sustainability certificatesRoHS, ENERGY STAR
Operating temperature (T-T)5 - 35 °C
Operating relative humidity (H-H)20 - 80 %
Mac operating systems supportedMac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms64-bit WEP, 128-bit WEP, WPA, WPA-AES, WPA-TKIP, WPA2, WPA2-AES, WPA2-PSK, WPA2-TKIP
Input voltage100 - 240 V
Power supply typeAC
AC input frequency50 - 60 Hz
Power consumption (sleep)1.6 W
Power consumption (typical)17 W
USB version3.2 Gen 2 (3.1 Gen 2)
Frequency band2.4/5 GHz GHz
USB connector typeUSB Type-B
Standard interfacesUSB 1.1, USB 2.0, USB 3.2 Gen 1 (3.1 Gen 1), Wireless LAN
Harmonized System (HS) code84716070
Weight and Dimensions IconWeight and Dimensions
Depth161 mm
Width292 mm
Height152 mm
Weight3400 g
