Fujitsu ScanSnap iX1500 User Manual

ATTENTION
l Load all documents over one another above the pick roller (center). Documents that are not
loaded above the pick roller cannot be fed.
Incorrect
Pick Roller Assembly's Width
l Adjust the side guides to the widest document. If the side guides are not adjusted properly, a
paper jam may occur.
l Load smaller documents so that they can be scanned straight.
If the documents are skewed during scanning, the following problems may occur:
- Part of the document does not appear in the scanned image
- Slant lines appear in the scanned image
- The documents are scanned in a wrong paper size
If the documents are not scanned straight, it is recommended that you select the [Continue
scanning after last page] checkbox in the [Scanning] tab of the "ScanSnap Setup Window"
(page 89), separate the documents by their widths, and scan them in different batches.
8. Press the [Scan] button on the ScanSnap to start a scan.
ATTENTION
Do not perform the following operations during scanning. Doing so will stop scanning.
l Connect or disconnect the ScanSnap and other USB devices.
l Close the ADF paper chute (cover).
Scanning Documents with S1300i
312

Fujitsu ScanSnap iX1500 Specifications

General

Color scanning	Yes
Maximum scan size	216 x 3000 mm
ADF scan speed (color, A4)	30 ppm
Optical scanning resolution	600 x 600 DPI
Black/white scanning color modes	Grayscale, Monochrome
Display	TFT
Scanner type	ADF + Manual feed scanner
Product color	White
Display diagonal	4.3 \
Scan to	Cloud
Sensor type	Dual CIS
Scan drivers	ScanSnap
Daily duty cycle (max)	- pages
Auto document feeder (ADF) input capacity	50 sheets
Maximum scan length	3000 mm
Card thickness (max)	0.76 mm
ISO A-series sizes (A0...A9)	A3, A4
ISO B-series sizes (B0...B9)	B4
Scanning media types supported	Plain paper
Maximum ISO A-series paper size	A3
Cables included	AC, USB
PC connection	USB 3.2 Gen 1 (3.1 Gen 1)
Sustainability certificates	RoHS, ENERGY STAR
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Mac operating systems supported	Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-AES, WPA-TKIP, WPA2, WPA2-AES, WPA2-PSK, WPA2-TKIP
Input voltage	100 - 240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Power consumption (sleep)	1.6 W
Power consumption (typical)	17 W
USB version	3.2 Gen 2 (3.1 Gen 2)
Frequency band	2.4/5 GHz GHz
USB connector type	USB Type-B
Standard interfaces	USB 1.1, USB 2.0, USB 3.2 Gen 1 (3.1 Gen 1), Wireless LAN
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	161 mm
Width	292 mm
Height	152 mm
Weight	3400 g
