Fujitsu ScanSnap iX1500 User Manual

No. Name Description
7 [Scan] button (*1) Starts scanning. Can be pressed even when the stacker is closed.
Indicates the status of the ScanSnap as follows:
Blue (lit): Ready
Blue (flashing): Scanning
Orange (flashing): Error
8 Stacker Pull it out to use it.
Stacks up the ejected documents.
9 Receipt Guide Attach it to the ADF paper chute (cover) for it to be used.
If you use the Receipt Guide, you can place documents with different
widths such as receipts in it to scan them at the same time.
*1: When the ScanSnap has turned off automatically because of the automatic power off function,
perform the following to turn the ScanSnap back on.
l iX1600/iX1500
Press the touch panel, or close the ADF paper chute (cover) and open it again
l iX1400
Press the [Scan] button (this will not start scanning), or close the ADF paper chute (cover)
and open it again
For details, refer to "Automatic Power OFF (iX1600 / iX1500 / iX1400 / iX500 / iX100 / SV600 /
S1300i)" (page 100).
Back
10
11
12
13
No. Name Description
10 USB connector Slide the cover of the USB connector up to open it and then connect
the USB cable to the USB connector.
The cover of the USB connector slides up either one or two levels.
Open the cover according to the type of the USB cable you have.
l First level: USB 2.0 cable
l Second level: USB 3.0 cable
11 Power connector Used to connect a power cable.
12 Security cable slot Used to connect an anti-theft security cable (commercially available).
13 Ventilation port Holes for ventilating hot air from inside the ScanSnap.
Parts and Functions
70

Fujitsu ScanSnap iX1500 Specifications

General

Color scanning	Yes
Maximum scan size	216 x 3000 mm
ADF scan speed (color, A4)	30 ppm
Optical scanning resolution	600 x 600 DPI
Black/white scanning color modes	Grayscale, Monochrome
Display	TFT
Scanner type	ADF + Manual feed scanner
Product color	White
Display diagonal	4.3 \
Scan to	Cloud
Sensor type	Dual CIS
Scan drivers	ScanSnap
Daily duty cycle (max)	- pages
Auto document feeder (ADF) input capacity	50 sheets
Maximum scan length	3000 mm
Card thickness (max)	0.76 mm
ISO A-series sizes (A0...A9)	A3, A4
ISO B-series sizes (B0...B9)	B4
Scanning media types supported	Plain paper
Maximum ISO A-series paper size	A3
Cables included	AC, USB
PC connection	USB 3.2 Gen 1 (3.1 Gen 1)
Sustainability certificates	RoHS, ENERGY STAR
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Mac operating systems supported	Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-AES, WPA-TKIP, WPA2, WPA2-AES, WPA2-PSK, WPA2-TKIP
Input voltage	100 - 240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Power consumption (sleep)	1.6 W
Power consumption (typical)	17 W
USB version	3.2 Gen 2 (3.1 Gen 2)
Frequency band	2.4/5 GHz GHz
USB connector type	USB Type-B
Standard interfaces	USB 1.1, USB 2.0, USB 3.2 Gen 1 (3.1 Gen 1), Wireless LAN
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	161 mm
Width	292 mm
Height	152 mm
Weight	3400 g
