3. Remove the brake roller from the shaft.
4. Attach the new brake roller to the shaft.
Insert the shaft to the brake roller by aligning the protrusion on the shaft with the slot on the
brake roller.
5. Attach the shaft to the ScanSnap.
Insert the left end of the shaft in the hole properly, and then attach the right side of the
shaft into place.
Replacing Consumables
129
