Fujitsu ScanSnap iX500

Extension
Stacker
7. Load the documents in the ADF paper chute (cover).
Load the documents face-down and top-first with their back facing you. Adjust the number of
documents so that they do not go beyond the reference marks and are kept within the side
guides when they are loaded.
Side Guide
ATTENTION
l Do not accumulate more than 50 sheets (with paper weight of 80 g/m
2
[20 lb]) in the stacker.
l When the [Place document face up] checkbox is selected in the [Scanning mode option]
window, load the documents face-up and bottom edge down.
To open the [Scanning mode option] window, click the [Option] button in the [Scanning] tab of
the "ScanSnap Setup Window" (page 45).
Scanning a Document
21
