A-1
APPENDIX
A
Server Views
Appendix A provides views of the server. It contains the following sections:
■ Section A.1, “The Server Views” on page A-1
■ Section A.2, “Operator Panel Overview” on page A-4
A.1 The Server Views
FIGURE A-1 shows a front view of the server.
FIGURE A-1 Server (Front View)
Location number Name Abbreviation
1 Fan unit FAN_A#0
2 Fan unit FAN_A#1
3 Operator panel OPNL
3
4
5
6
7
8
1
2
