Ports and controls
Left-hand side
2 3 4 5 6 71
1 = Tether eyelet
2 = Combined headphones and microphone
port (audio combo jack)
3 = USB 3.0 port (protected by cover)
4 = microHDMI port (protected by cover)
5 = microSD card slot (protected by cover)
6 = Battery charging indicator (orange)
7 = DC input connector (DC IN)
(protected by cover)
Right side
1 2
1 = Stylus garage
2 = Tether eyelet
Fujitsu 11
