Fujitsu STYLISTIC Q Series

To Next Page

To Previous Page

Accessories for your Tablet PC (opti

onal)

Adapter cables

3 adapter cables are available for the device:

* USB Type-C to HDMI

* USB Type-C to microHDM

For technica

l specifications, see chapter "

Adapter cables (optional)", Page 79.

54 Fujitsu
