Working with the Tablet PC

Inserting the memory card

► Open the slot cover (1).

► Carefully slide the storage card into the slot (2). The label area must be facing downward.

Do not apply any force, otherwise the delicate contact surfaces could be damaged.

Memorycard

► Close the slot cover.

Fujitsu 35
