Technical data
WLAN specif cations
Type of network
Intel® Dual Band Wireless-AC 7265 2x2
ac/a/b/g/b/n with integrated Bluetooth 4.1, Wi-Fi
based*
2.4 GHz min. 2412, max. 2472 5.8 GHz
min. 5180, max. 5825
Transfer rate
(
A
utomatic switching) IEEE802.11 a and g: 54
Mbps max. data rate; IEEE802.11n: 300 Mbps max. data
r
ate, IEEE802.11ac: 867 Mbps max. data rate
Typical operat
ing distances**
Number of channels
• 802.11a: 8 independent channels
• 802.11b/g: 11 channels, 3 non-overlapping
channels
• 802.11n: Channel bonding takes two of
the non-overlapping 20MHz channels and
combines it into one 40MHz channel. It is
actually 12 non-overlapping channels with
channel bonding and 24 without. Also it is 1
non-overlapping channel in 2.4GHz when
channel bonding is used.
•
802.11ac: 5 independent channels
Security
E
ncryption types: compatible with WEP, TKIP,
AES***, WPA 1.0 and WPA 2.0
Encryption key, lengths supported: 64 bits and
128 bits
Maximum recommended number of computers to be
c
onnected over wireless LAN (during ad hoc connection)
10 unit
s or less ****
* “Wi-Fi based” indicates that the interconnectivity test of the organization which guarantees the interconnectivity of wireless
LANs (Wi-Fi Alliance) was passed.
** The operating distances given above increase or decrease depending on factors such as the number of walls, reflecting material
or interference by external RF sources.
*** Network key encryption (WEP) occurs with the number of bits given above, after deduction of the fixed length of 24 bits the user
may however also set 40 or 104 bits.
**** Depending on the particular practical application, the number of computers which can be networked is reduced if
necessary.
76 Fujitsu
Active frequency
• 802.11n: 2.4 GHz or 5 GHz
• 802.11b/g: 2400~2473 MHz
• 802.11a: 4900~5850 MHz
• 802.11ac: 2.4 GHz / 5 GHz
• 802.11a: 40 ft. (12 m) @ 54 Mbps; 300 ft.
(91 m) @ 6 Mbps
• 802.11ac: 40 ft. (12 m) @ 54 Mbps; 300 ft.
(91 m) @ 6 Mbps
• 802.11b: 100 ft. (30 m) @ 11 Mbps; 300 ft.
(91 m) @ 1 Mbps
• 802.11g: 100 ft. (30 m) @ 54 Mbps; 300 ft.
(91 m) @ 1 Mbps
• 802.11n: Estimated double the oper
ating
distance of 802.11g and 802.11a in their
respective frequencies
