Bold italic: Default
Initial Setup Status (RX Only (Shows the status of AIS.))
SART Test RX (OFF, ON)
Ship Static
MMSI (Shows the MMSI number.)
Ship Name (Enter the ship’s name.)
Call Sign (Enter the call sign.)
Ship Type (0: Not Available or No ship, 1: Reserved for Future Use, 2: WIG,
3: Vessel, 4: HSC, 5: Special Craft, 6: Passenger Ships, 7: Cargo Ships,
8: Tanker(s), 9: Other Types of Ship)
Cargo Type (Options are differ depending on the setting in [Ship Type].)
Serial Number (Shows the serial number for the equipment.)
Antenna Position (GNSS) (A/B: 0 to 511 m; 0 m, C/D: 0 to 63 m; 0 m)
IO Setup Common
Port Priority (Heading)
1st (NMEA2000, NMEA1, NMEA2)
2nd (NMEA2000, NMEA1, NMEA2)
3rd (NMEA2000, NMEA1, NMEA2)
NMEA2000
CAN Unique Number (Shows the CAN unique number.)
CAN Address (Shows the CAN address.)
Output Mode (OFF, AIS, GNSS, AIS + GNSS)
Format (NMEA2000 V2, NMEA2000 V1)
NMEA0183
NMEA1 / NMEA2
Output Mode (OFF, AIS, GNSS, AIS + GNSS)
Speed (AIS: 38400 bps, Sensor: 4800 bps)
*1
Output GNSS (OFF, GGA + VTG Sentences, GLL + VTG Sentences,
RMC Sentence)
*2
Own Vessel Data View Channel
CH A: (Shows the channel number and RX mode for channel A.)
CH B: (Shows the channel number and RX mode for channel B.)
Channel Edit
CH Mode (Auto, Manual)
CH A (When [CH Mode] is [Manual], set the channel number for channel A.)
CH B (When [CH Mode] is [Manual], set the channel number for channel B.)
Sensor Status (Shows the sensor information.)
GNSS Status (Shows the GNSS information.)
Alert Status (Shows the alerts currently occurred.)
Alert Log (Shows the alerts occurred in the past.)
Tests Test Start (Starts the test.)
Transponder Test (Shows the self test result for the FA-40.)
GNSS Test (Shows the self test result for the internal GNSS core.)
Clear GNSS (Clears the GNSS test result.)
IO Monitor Port (NMEA1, NMEA2, NMEA2000)
*2
: These options are selectabled when [Output
Mode] is set to [GNSS] or [AIS + GNSS].
*1
: Fixed to [AIS: 38400 bps] when [Output Mode]
is set to [AIS] or [AIS + GNSS].
