vi
SYSTEM CONFIGURATION
Antenna Unit
GPA-017S,
GPA-017,
or GPA-C01
VHF Antenna
CX4-3/FEC
AIS Receiver FA-40
PC
NMEA2000 Sensor
or External Display
: Standard supply
: Optional or local supply
NAV Equipment
or Sensor
Ship’s Mains 12-24 VDC
NAV Equipment or Sensor
POWER
ERROR
RX
