Furuno FELCOM 500

 9.4 Antenna Unit: FB-1500
9-18
Fig. 9.4.11 Front end Module (ATB & LNA)
Fig. 9.4.11 Front end Module (ATB & LNA)
ATB Module
LNA Module
Clinometer:
Inclination sensor
Fig. 9.4.12 Front end Module
and Cross EL drive -1
Fig. 9.4.13 Front end Module
and Cross EL drive -2
Cross EL drive
p
art
EL belt
