48
Functions
Model Select / SEL
Use this function to call a new model number, or to change a set model number, to set
new model data.The T3PM transmitter can store the model data for ten R/C cars.
Calling model memories of different modulation modes (HRS, PPM)
After the new model is called, signals are still output in the old model modulation
mode until the transmitter power is turned off. Before using the new modulation
mode, turn the power off and on. (See page 53 for the HRS/PPM mode selection.)
Model Select
1 (Model No. selection)
Use the (CH) button to select the model No.
2 (Select execution)
Press the (+) and (-) buttons simultaneously for about 1 second.
3 When ending adjustment, return to the initial screen by pressing the (SEL)
button.
(Initial screen)
Press "SEL" key to select the
desired function screen.
Calling the setup screen
(Setup screen)
Press "CH" key to select the next set-
up screen.
Model name
Model number:
01 ~ 10
To Next Page
