Reference
Reference
Ratings
*Specifications and ratings are subject to change without prior notice.
Transmitter T3PM
(Wheel system, 3 channels)
- Transmitting frequencies 27, 29, 40,
41 or 75MHz band
- Modulation FM
(HRS/PPM switching possible)
- Power requirement
(NiCd battery)
NT8F700B NiCd battery (9.6V)
(Dry cell battery)
Penlight x 8 (12V)
- Current drain 250mA or less
Servo S3305
(Heavy duty metal gear servo)
- Output torque 8.9kg-cm (124oz-in)
- Speed 0.2 sec/60 degree
- Power requirement 4.8V or 6V
- Size 40x20x38.1mm
(1.57x0.79x1.50in)
- Weight 46.5g (1.64oz)
Receiver R203HF
(3 channels, HRS receiver)
- Receiving frequencies 27, 29, 40, 41
or 75MHz band
- Intermediate frequency 455kHz
- Power requirement 6.0V
(shared with servos)
- Current drain 14mA
- Size 25.6x37.7x14.3mm
(1.01x1.48x0.56in.)
- Weight 17g (0.6oz.)
In case of the High Response Sys-
tem (H.R.S) receiver R203HF, al-
ways use only the following condi-
tions:
Servo; 6V type Digital Servo only
Power supply; 6V Nicd battery
Transmitter setting; "HRS" mode
If the conditions are different, control is impossible.
And Fail Safe Unit (FSU1) is not available.
Caution
Servo S3003
(Standard servo)
- Output torque 4.1kg-cm (56.9oz-in)
- Speed 0.19 sec/60 degree
- Power requirement 4.8V or 6V
- Size 40.4x19.8x36mm
(1.59x0.78x1.42in)
- Weight 37.2g (1.31oz)
Receiver R303FS
(3 channels, FM, PLL synthesizer receiver)
- Receiving frequencies 27, 29, 40, 41
or 75MHz band
- Intermediate frequency 455kHz
- Power requirement 4.8V or 6V
(shared with servos)
- Current drain 35mA
- Size 28.5x42.7x13mm
(1.12x1.68x0.51in.)
- Weight 18.8g (0.66oz.)
Receiver R133F
(3 channels, FM receiver)
- Receiving frequencies 27, 29, 40, 41
or 75MHz band
- Intermediate frequency 455kHz
- Power requirement 4.8V or 6V
(shared with servos)
- Current drain 18mA
- Size 25.6x37.6x13.8mm
(1.01x1.48x0.54in.)
- Weight 14.6g (0.52oz.)
