UM-STO-C Revision C 16
Operators and Technicians
PSA-66-001N
3 –
release the finger latches
to eject the ribbon cable
Be sure to note that the black end of the ribbon cable connects to the rear
daughter board (Gray end of cable connects to main controller.
Release the ribbon cable by spreading the finger latches at the rear of the unit:
