APPENDIX "A" - COMPATIBLE DEVICES
2-WIRE DETECTOR CONTROL PANEL COMPATIBILITY
The Underwriter’s Laboratories Inc. (UL) Listed 2 Wire Initiating Devices identified below have been verified by
UL to be electrically compatible with Flex 4/Flex 8 Initiating Device Circuits with Compatibility Identifier "GWC01".
Do NOT exceed 3 millianperes of total detector standby current whether mixing different models of compatible
detectors, or using the same model on the same Circuit,
GAMEWELL
MODEL
COMPATIBILITY
IDENTIFIER
STANDBY
CURRENT
GAMEWELL
MODEL
COMPATIBILITY
IDENTIFIER
STANDBY
CURRENT
60 Series(Head/Base) 60 Series(Head/Base)
71033/71036 71033/71036 0.110mA 71035-160/71036 71035-160/71036 0.057 mA
71033/71086 71033/71086 0.110mA 71035-160/71086 71035-160/71086 0.057 mA
71033/71086-LOW 71033/71086-LOW 0.110mA 71035-160/71086-LOW 71035-160/71086-LOW 0.057 mA
71034/71036 71034/71036 0.081mA 71035-210/71036 71035-210/71036 0.057 mA
71034/71086 71034/71086 0.081mA 71035-210/71086 71035-210/71086 0.057 mA
71034/71086-LOW 71034/71086-LOW 0.081mA 71035-210/71086-LOW 71035-210/71086-LOW 0.057 mA
71035/71036 71035/71036 0.057mA 71443/71036 71443/71036 0.185 mA
71035/71086 71035/71086 0.057mA 71443/71086 71443/71086 0.185 mA
71035/71086-LOW 71035/71086-LOW 0.057mA 71443/71086-LOW 71443/71086-LOW 0.185 mA
30954 30954 0.081mA 30955 30955 0.110 mA
Additions to the device compatibility list for the Gamewell Flex 4 and Flex 8 control panel are frequently being investigated. Please contact
Gamewell for the latest information if the Gamewell device you desire is not included in the preceding tables.
4-WIRE DETECTOR CONTROL PANEL COMPATIBILITY
Any Underwriter’s Laboratories Inc. (UL) Listed separately powered alarm initiating device (e.g.smoke or heat detector) having an operating
voltage range equal to or exceeding the output of the Flex 4 or Flex 8 and having a dry contact for alarm initiating is electrically compatible. Be
certain to install a end of line, Listed power supervision module after the electrically last initiating device on each circuit. For ease in trouble
determination, use one supervision module per Initiating Circuit in which 4 wire type powered initiating devices are installed with a separate power
run for each initiating circuit. Operation for alarm of any contact type initiating device installed on the same circuit with two wire type (loop powered)
device(s) will cause any previously operated two wire to reset and prevent operation for alarm of any other loop powered device on that circuit.
60 Series
71033/71393 71034/71393 71035/71393 71035-160/71393 71035-210/71393
NOTIFICATION APPLIANCE CONTROL PANEL COMPATIBILITY
Any Underwriter’s Laboratories Inc. (UL) Listed Notification Appliance with 20 - 30 volts DC or FWR operating voltage range is electrically
compatible with the Flex 4 and Flex 8.
GAMEWELL offers many Notification Appliances compatible with the Flex 4 and the Flex 8 including; All model PH Series wall mounted Horns,
PHS Series wall mounted Horn/Strobes, PS Series wall mounted Strobes, PSS Series wall mounted Speaker/Strobes, PCHS Series ceiling
mounted Horn/Strobes, PCS Series ceiling mounted Strobes, PCSS Series ceiling mounted Speaker/Strobe and Sync-Circuit modules MDL or
MDLW.
APPENDIX "B" - RA8 REMOTE ANNUNCIATOR
The RA8 Eight Zone Remote Annunciator mounts in an electrical box. It provides annunciation for the Flex 4 or
Flex 8's full complement of 8 Initiating circuits.
For wiring connection information refer to the installation and operation manual part number 71954-02.
