APPENDIX "C" - MODULE SPECIFICATIONS and FEATURES
Fire Alarm Control Panel (Flex 4)
General:
M 4 Style B (Class B) or 2 Style D (Class A) Supervised Initiating
Circuits; configurable. [Compatibility ID “GWC01”]
Power Limited: 26VDC, 3 mA standby, 1.5Vp-p ripple,
50 mA max. (alarm)
M One CEM Circuit Expander Module may be added.
M 2 Style Y or Z (Class A/B) Indicating Circuits; configurable for
strobes or audibles.
Power Limited: 24 VDC unfiltered
1.7 A @ 49C per Circuit
M Initiating Circuit Disconnect Switches.
M Optional DACT Digital Alarm Communicator
or PRM City Tie Module.
M Optional RY4 / RY8 Relay Module.
M Resettable 4-Wire Detector Supply.
Power Limited: 28VDC, 100mA max, 1.5Vp-p ripple
M Auxiliary Power Supply.
Power Limited: 24VDC, 300mA max, unfiltered
for RTI or Remote Annunciators
M 1 RS-485 Connection for up to 3 RA8 Remote Annunciators.
M 1 Interface for connection to an RTI Remote Trouble Indicator.
M Auxiliary relays: (resistive loads)
Common Alarm, Supervisory, Trouble
All are Form C, 1Amp, 28VDC
M Micro-controller Based Design.
M DIP Switch Configurable.
M Walk-Test function.
Electrical ratings:
M AC Line Voltage: 102 to 132 VAC.
4 Amps (primary, 4A circuit breaker)
M Pwr Supp. ratings: 6 Amps. max. (secondary)
M For Indicating Circuits: 24VDC unfiltered (5 Amps. max.)
M Battery: 24VDC, Gel-Cell/Sealed Lead-Acid
Charging capability: 10 to 24 AH batteries
Fuse on Main Board: 10 Amps.
M Current Consumption: Standby: 110 mA, Alarm: 220 mA
Circuit Expander Module CEM)
M May be added to Flex 4.
M 4 Style B (Class B) or 2 Style D (Class A) Supervised Initiating
Circuits; configurable. [Compatibility ID “GWC01”]
Power Limited: 22VDC, 3 mA standby, 1.5Vp-p ripple,
50 mA max. (alarm)
M 2 Style Y or Z (Class B or A) Indicating Circuits; configurable
for strobes or audibles.
Power Limited: 24 VDC unfiltered, 1.7A @49C per Circuit
M Current Consumption: Standby: 45 mA, Alarm: 120 mA
8 Zone Remote Annunciator (RA8)
M RS-485 Interface, up to 3 per Flex 4 or Flex 8 Panel.
M Current Consumption: Standby: 35 mA, Alarm: 90 mA
Remote Trouble Indicator (RTI)
M Trouble LED and Trouble Buzzer
M Current Consumption: Standby: 35 mA, Alarm: 35 mA
End-of-Line Resistor (30177)
M UL Listed 3.9 Kohm, 1/2 Watt, 5% Resistor. Spade Lugs
DACT / Digital Alarm Communicator (DACT)
M DACT - “Digital Alarm Communicator Transmitter”
Uses Ademco Contact ID and SIA-DCS Protocols.
M Current Consumption: Standby: 45 mA, Alarm: 120 mA
Fire Alarm Control Panel (Flex 8)
General:
M 8 Style B (Class B) or 4 Style D (Class A) Supervised Initiating
Circuits; configurable. [Compatibility ID “GWC01”]
Power Limited: 26VDC, 3 mA standby, 1.5Vp-p ripple,
50 mA max. (alarm)
M 4 Style Y or Z (Class A/B) Indicating Circuits; configurable for
strobes or audibles.
Power Limited: 24 VDC unfiltered
1.7 A @ 49C max per Circuit 5 Amperes
maximum per control panell
M Initiating Circuit Disconnect Switches.
M Optional DACT Digital Alarm Communicator
or PRM City Tie Module.
M Optional RY4 / RY8 Relay Module.
M Resettable 4-Wire Detector Supply.
Power Limited: 28VDC, 100mA max, 1.5Vp-p ripple
M Auxiliary Power Supply.
Power Limited: 24VDC, 300mA max, unfiltered
for RTI or Remote Annunciators
M 1 RS-485 Connection for up to 3 RA8 Remote Annunciators.
M 1 Interface for connection to an RTI Remote Trouble Indicator.
M Auxiliary relays: (resistive loads)
Common Alarm, Supervisory, Trouble
All are Form C, 1Amp, 28VDC
M Micro-controller Based Design.
M DIP Switch Configurable.
M Walk-Test function.
Electrical ratings:
M AC Line Voltage: 102 to 132 VAC.
4 Amps (primary, 4A circuit breaker)
M Pwr Supp. ratings: 6 Amps. max. (secondary)
M For Indicating Circuits: 24VDC unfiltered (5 Amps. max.)
M Battery: 24VDC, Gel-Cell/Sealed Lead-Acid
Charging capability: 10 to 24 AH batteries
Fuse on Main Board: 10 Amps.
M Current Consumption: Standby: 110 mA, Alarm: 220 mA
Model: RY4 and RY8 Relay Module
M Four or Eight Relays: Form C, 1A (resistive), 28 VDC contacts
M Each individual relay can be: Relay per Zone, Common Alarm,
Common Supervisory
M Module Current Consumption: Standby: 5 mA, Alarm: 160 mA
Polarity Reversal and City Tie Module (PRM)
M Supervised City Tie Not Power Limited
24VDC unfiltered, 210 mA max., Trip coil: 14 ohms
M Polarity Reversal Power Limted
24VDC open, 12VDC @ 3.5 mA, 8 mA max. (shorted)
M Current Consumption: Standby: 35 mA, Alarm: 300 mA
System Model: Flex 4 and Flex 8 Fire Alarm Control Panels
System Type: Local, Auxiliary (using PRM), Remote Station
Protected Premises (using DACT or PRM), Central Station Protected
Premises (using DACT).
Type of Service: A, M, WF, SS (SS is only Local or with DACT)
Type of Signalling: Non-Coded
Applicable Standards: National Electrical Code NFPA 70
National Fire Code NFPA 72
UL Standard 864
