APPENDIX "D" - POWER SUPPLY & BATTERY CALCULATIONS (SELECTION GUIDE)
Use the form below to determine the required Secondary Power Supply (batteries).
IMPORTANT NOTICE
The main AC branch circuit connection for Fire Alarm Control Unit must provide a dedicated continuous power without provision of any
disconnect devices. Use #12 AWG wire with 600-volt insulation and proper over-current circuit protection that complies with the local codes.
Refer to appendix "C" for specifications.
POWER REQUIREMENTS (ALL CURRENTS ARE IN AMPERES)
Model Number Description Qty STANDBY TOTAL
STANDBY
ALARM TOTAL
ALARM
Flex 4 Fire Alarm Control Panel X 0.110 = 0.220 =
Flex 8 or
Flex 4 with CEM
Fire Alarm Control Panel or
Fire Alarm Control Panel w/
Circuit Expander Module
X 0.155 = 0.340 =
RY4 / RY8 Relay Module X 0.005 = 0.160 =
PRM City Tie Module X 0.035 = 0.300 =
DACT Digital Alarm
Communicator Module
X 0.045 = 0.120 =
RA8 Remote Annunciator X 0.035 = 0.090 =
RTI Remote Trouble Indicator X 0.035 = 0.035 =
71033 or 30955 Photo Smoke Detector X 0.000110 = 0.052 =
71034 or 30954 Ion Smoke Detector X 0.000081 = 0.052 =
71035 or 71035-160 or 71035-210 Heat Detector X 0.000057 = 0.052 =
71443 Combination Photo/Heat Detector X 0.000185 = 0.052 =
Signal Load (bells, horns, strobes, and etc.) = =
Auxiliary Power Supply for Annunciators, etc. =
ALARM
=
Total currents (Add above currents) STANDBY
(A) (B)
Total Current Requirement: ALARM (B)______ Amps.
Battery Capacity Requirement:
([STANDBY (A) ______ ] X [(24 or 60 Hours) ___ ]) + ([ALARM (B) ______ ] X [***Alarm in Hr.] _____) = (C) ______AH
Total Alarm Current: Must be 6 amperes or less. Indicating Circuits not to exceed 5 amperes.
Battery Selection: Multiply (C) by 1.20 to derate battery.
The control panel will charge up to 24AH Batteries in a separate Listed enclosure.
*** Use 0.084 for five minutes of alarm as a multiplier figure.
Examples: Configuration 24 Hrs Standby, 5 Min Alarm 60 Hrs Standby, 5 Min Alarm
Flex 4 Basic (2A alarm) 4 AH Batteries 8 AH Batteries
Flex 4, DACT, RY8 (2A alarm) 7.0 AH Batteries 12 AH Batteries
Flex 8 (Flex 4 with CEM) (4A alarm) 12 AH Batteries 12 AH Batteries
Flex 8 (Flex 4 with CEM) , DACT, RY8, 12 AH Batteries 24 AH Batteries
3 x RA8 (4A alarm)
