Appendix A: Interface 5000 Specifications
61
Galvanostatic Mode
Maximum Full Scale Current
±5
A
Minimum Full Scale Current
±50
µA
Accuracy
Dominated by current-to-voltage
converter accuracy shown above
Sig Gen Voltage for Full Scale Current
±3.0 V
Temperature Measurement
Measurement range
–50 to 600
°C
Accuracy of measurement
Typ
RTD error ± 0.3
°C
Note 24
RTD resistance at 0°C
Typ
1000
Ω
RTD’s temperature coefficient of
resistance, 0 to 100°C range
Typ
0.00385
Ω/°C
Note 25
Temperature-reading display
°C rounded to one decimal point
°C
RTD connection
Customer-provided
Note 26
RTD calibration
Customer-provided, if required
Environmental
Operating Temperature Range
0 to +45
°C
Relative Humidity
Max
90 (non-condensing)
%
Storage and Shipping Temperature
–25 to +75
°C
Maximum Shipping Acceleration
30
g
General
DC Power Input Voltage
Range
46 to 50
V
Power
Max
85
W
Leakage Current (floating, earthed
working electrode)
Typ
±10
nA
Note 27
Dimensions
24 × 27 × 6
cm
Note 22
Weight
Max
2.5
kg
Note 22
Dimensions of External Power Adapter
Max
14.7 × 6.7 × 3.4
cm
Note 23
Weight of External Power Adapter
Max
450
g
Note 23
NOTES:
1. Measured in galvanostatic mode with a high-power 2.4  load resistor connected from the counter to the
working electrode leads. The compliance voltage is measured using an external voltmeter across the 2.4 
load. Under these conditions, the output current is approximately 2.72 A.
