Gardner Denver AUTO SENTRY EAU99G - Figure 2-5 - Heat Exchanger (Oil Cooler) Approximate Water Flow; Figure 2-6 - Aftercooler Approximate Water Flow

13-10-614 Page 15
HEAT EXCHANGER (INTERNATIONAL)
Water Temperature to Heat
Exchanger
(ls)
KW Model
16° C 21° C 27° C 32° C
Maximum
Water Flow
(ls) *
Approximate Water
Pressure Drop @ 32° C
Water Temperature Bar
150 EAU99H 1.2 1.5 2.0 3.0 7.0
186 EAU99H 1.5 1.9 2.5 3.8 7.0
224 EAU99H 1.8 2.3 3.1 4.6 7.0
Less than .15 bar for any
flow rate shown in the
table
* Flows exceeding "Maximum Water Flow" will cause severe erosion and will void unit warranty.
Figure 2-5 – HEAT EXCHANGER (OIL COOLER) APPROXIMATE WATER FLOW
AFTERCOOLER (DOMESTIC)
Water Temperature to Heat
Exchanger
(gpm)
HP Model
60° F 70° F 80° F 90° F
Maximum
Water Flow
(gpm) *
Approximate Water
Pressure Drop @ 90° F
Water Temperature
(psi)
200 EAU99G & M 3.0 3.7 5.0 7.5 110
250 EAU99G & M 3.8 4.8 6.4 9.5 110
300 EAU99G & M 4.6 5.8 7.7 11.6 110
Less than 1 psi for any flow
rate shown in the table
* Flows exceeding "Maximum Water Flow" will cause severe erosion and will void unit warranty.
AFTERCOOLER (INTERNATIONAL)
Water Temperature to Heat
Exchanger
(ls)
HP Model
16° C 21° C 27° C 32° C
Maximum
Water Flow
(ls) *
Approximate Water
Pressure Drop @ 32° C
Water Temperature BAR
150 KW EAU99H 0.2 0.2 0.3 0.5 7.0
186 KW EAU99H 0.2 0.3 0.4 0.6 7.0
224 KW EAU99H 0.3 0.4 0.5 0.7 7.0
Less than .1 bar for any
flow rate shown in the table
* Flows exceeding "Maximum Water Flow" will cause severe erosion and will void unit warranty.
Figure 2-6 – AFTERCOOLER APPROXIMATE WATER FLOW
