Page 21
490X Engineer’s Reference Guide
16) Enter the Zone number you wish to
program the Descriptor for followed by Yes.
The display will show for example:-
17) Press No. The display will show:-
18) You should now program the Descriptor you
require using the template below for the
key allocation in a similar way that you you would
type a text message on a mobile telephone.
As the desired character is displayed press the
Yes key to move on to the next character.
Continue until the line is complete.
1 2 3
ABC DEF GHI
4 5 6
JKL MNO PQR
7 8 9
STU VWX YZ Space
No 0 Yes
Delete 1234567890 Enter Character
19) As you enter the last character the display
will move on to the next Zone. For example:-
20) Repeat from Step 16 until all the Descriptors
you require have been programmed. Then
press 0 (zero) key twice.
The display will show:-
Zone 001 Name =
Zone 001
Zone 001 Name =
Zone 001
Zone 001 Name =
_
Program Zone
Descriptors ?
490X 1.qxd 11/07/2006 12:32 Page 21
