GARDTEC GT490X - Wiring Proximity E & I Readers

Page 95
490X Engineer’s Reference Guide
Wiring Proximity ‘E’ and ‘I’ Readers
‘I’ Reader Terminals RKP Terminals
Single ‘E’ Reader up to 7.5m
‘E’ Reader Wiring RKP Terminals
Single ‘E’ Reader 7.5m to 15m
‘E’ Reader Wiring RKP Terminals
Details on wiring multiple Readers are provided with the Reader.
ANT SET
0V
ANT SET
0V
ANT SET
0V
‘E’ Reader Wiring
RED
BLUE
YELLOW
BLACK
ANT SET
0V
‘E’ Reader Wiring
RED
GREEN
YELLOW
BLACK
490X 1.qxd 11/07/2006 12:32 Page 95
