Page 56
490X Engineer’s Reference Guide
51) Press No until the required setting is displayed
then press Yes. The display will show:-
This option determines what Digi Channels will send a Restore Signal to Central
Station when the system is Reset. Most Central Stations will require a Restore
Report for all channels.
52) Press No. The display will show:-
53) Enter eight ones so the display shows:-
54) Press Yes. The display will show:-
Channel 4 normally needs an inversion of the signal that is sent to Central
Station. By having 4 as the setting for this option channel 4 will be inverted. If
you have reports from the Central Station that the Open/Close channels are the
wrong way around proceed as follows to remove the inversion on the control
panel.
55) If you do not need to change this option press
Yes and jump to Step 57
Or
To change the setting. Press No.
The display will show:-
56) Press 0 followed by Yes. The display will show:-
Channel 1 2 3 4 5 6 7 8
R/Rep = 0 0 0 1 0 0 0 0
Channel 1 2 3 4 5 6 7 8
R/Rep = _ _ _ _ _ _ _ _
Channel 1 2 3 4 5 6 7 8
R/Rep = 1 1 1 1 1 1 1 1
Open/Close
Channel/s = 4
Open/Close
Channel/s > _ _
Program Advanced
Functions ?
