Wiring Diagrams - 490X PCB
Page 6
490X Engineer’s Reference Guide
- + -
STROBE BELL
BELL SAB PGM1 SPR+ SPR + - + - + - + - + - + - + - + - + - + - AON AIN AOUT
HOLD TMPR AUX 12V TZ AZ1 AZ2 AZ3 AZ4 AZ5 AZ6 AZ7 AZ8
RS485 REMOTE KEYPAD PGM2
RED BLK YEL GRN D2 D1 0V 12V
BATT AC
- +
PSTN OUT LINE IN
C3 B2 A5 B2 A5
F1 BATTERY 20mm
2A ANTI-SURGE
F2 AUX 20mm
1A QUICK BLOW
F3 KEYPAD 20mm
250mA QUICK BLOW
PATCH
LEAD
CONNECTION
TELEPHONE CONNECTIONS
KEYPAD
CONNECTIONS
RS485 (RADIO EXPANDER)
CONNECTIONS
EXTERNAL SOUNDER
/ STROBE MODULE
INTERNAL SPEAKERS
MIN 16 OHM
REMOTE
KEYPAD(S)
MAY BE WIRED
IN STAR OR
DAISYCHAIN
FORMAT
D2/B D1/A 0V 12V
D2/B D1/A 0V 12V
LINE
IN
3
2
5
OTHER
SOCKETS
ON PREMISES
Note: Only replace fuses
with correct type & value
GTAG
PROXIMITY
READER(S)
Note: 680 Ohm
resistor should
be fitted to ONE
of the RKPs. If
RKPs are wired
in daisy chain
this should be
the last RKP in
the line,
Strobe - Trigger
Bell / Strobe + Hold-Off
Bell - Trigger
Bell Hold-Off - Supply
- Tamper Return
Default Engineer Code
1234.
Default User
5678.
To Default Panel
Power Up.
Whilst version No.
is displayed enter
4 6 Yes No.
This will not Default
the Engineer Code
if it has been locked.
Connections available are
model dependant
680 Ohm
