Page 71
490X Engineer’s Reference Guide
7) Press No. The display will show:-
8) Enter the Zone Number or Customer Number
that you wish the output to follow then press
Yes. The display will show for example:-
9) Press No to select when you want the output to
operate followed by Yes. The display will show:-
10) Press No until the mode you require is displayed
then press Yes. The display will show:-
11) Press No. The display will show:-
12) Enter the time required followed by Yes.
The display will show:-
The t = 00 setting only applies to Fol+
Fol- Pul+ Pul-
13) Repeat Steps 5 to 13 until all the Custom
Outputs you require have been programmed.
When you have programmed Custom 8 the
display will show:-
14) Press 0 (zero) until the display shows:-
Program . . . . _ _ _
PGM1 / Custom ?
Cus 2 = Zone #=000
=Day = Fol+ t=00
Cus 1 = Zone #>_ _ _
=Day = Fol+ t=00
Cus 1 = Zone #>009
>Day = Fol+ t=00
Cus 1 = Zone #>009
+Day > Fol+ t=00
Cus 1 = Zone #>009
+Day = Fol+ t>00
Cus 1 = Zone #>009
+Day = Fol+ t> _ _
01 Jan 00: 00: 01
490X 1.qxd 11/07/2006 12:32 Page 71
