Garland MWE3W Service Manual

SERVICE MANUAL GARLAND CLAMSHELL GRILLS WITH PRODUCT RECOGNITION
PART #4526396 (03/30/10)Page 10
SPECIFICATIONS
SUPPLY
REQUIRED
TOTAL
KW
LOAD
NOMINAL AMPS PER LINE
208V 220V 240V
L1 L2 L3 L1 L2 L3 L1 L2 L3
INPUT 1 7.65 21.3 21.3 21.3 20.1 20.1 20.1 18.4 18.4 18.4
INPUT 2 15.30 42.6 42.6 42.6 40.2 40.2 40.2 36.8 36.8 36.8
SUPPLY
REQUIRED
TOTAL
KW
LOAD
NOMINAL AMPS PER LINE
208V 240V
L1 L2 L3 L1 L2 L3
INPUT 1 22.95 63.9 63.9 63.9 55.2 55.2 55.2
SUPPLY
TOTAL kW
LOAD
LOADING: (kW/PHASE) NOMINAL AMPS PER LINE
MENNEKES
PLUG &
RECEPTACLE
MAY BE
REQUIRED
230V / 400V 230V / 400V
3N~ 400V
50Hz
22.7
L1/L2 L1/L3 L2/L3 L1 L2 L3
7.60 7.60 7.60 33.0 33.0 33.0 Type 748
SUPPLY
TOTAL kW
LOAD
LOADING: (kW/PHASE)
NOMINAL AMPS PER LINE
MENNEKES
PLUG &
RECEPTACLE
MAY BE
REQUIRED
230V / 400V 230V / 400V
L1/L2 L1/L3 L2/L3 L1 L2 L3
220V 50Hz 22.7 7.60 7.60 7.60 34.5 34.5 34.5
Type 748
240V 50Hz 22.7 7.60 7.60 7.60 31.6 31.6 31.6
Input Specications, ELECTRIC FULL SIZE Grills, MWE3W, United States:
Input Specications, ELECTRIC FULL SIZE Grills, MWE3W, Western Canada:
Input Specications, Electric Grills, CE Approved Models MWE3W-CE, MWE3S-CE:
Input Specications, Electric Grills, Export, Non-CE Models MWE3W, MWE3S:

Garland MWE3W Specifications

General

Brand	Garland
Model	MWE3W
Category	Grill
Language	English
