Garmin 400C - Mounting the Transducer on a Trolling Motor

Fishnder 400C Owner’s Manual 
InstallIng the FIshFInder 400c
Mounting the Transducer on a Trolling Motor
(Dual Beam Transducers Only)
To mount the transducer on a trolling motor:
1. Slidethelargecabletiethroughtheslotonthetransducer
mountwiththeridgesofthebandfacingupuntilequal
lengthsextendonbothsidesofthemount.
NOTE: For cold water, or heavy timber or debris areas, a metal
4-5" worm gear clamp is recommended.
2. Positionthemountgasketonthecurvedtopofthe
transducermount.
3. Placethetransducerassemblyagainstthemotorbodyofthe
trollingmotor,withthefrontofthetransducerpointedaway
fromthetrollingmotorpropeller.
4. Wrapthetwoendsofthecabletiearoundthemotorbody.
Placethepointedendofthecabletiethroughthefastener
holeontheoppositeendandpullitthroughuntilitissnugbut
nottight.(Thecabletieclickswhenyoupullit.)
5. Positionthetransducersothatitisparallelwiththebottom
wheninuse,andmakesurethegasketisalignedproperly.
Pullthecabletieenduntiltight.Trimofftheexcessif
necessary.Tightenthe10-32lockingnutuntilittouchesthe
mountingbracket,andthentighten1/4turnmore.(Donot
overtighten.)
6. Routethe30-foot(9m)transducercableusingthesupplied
cabletiestosecurethecabletothemotorshaft.Youcanll
theforward-facingportion(exceptthecabletiepocket)ofthe
transducermountwithsealanttoavoidaccumulatingdebris.
Cable tie
Front of the transducer
