Garmin G1000 Pilot’s Guide for the Diamond DA42NG
190-00962-04 Rev. A580
ADDITIONAL FEATURES
SYSTEM
OVERVIEW
FLIGHT
INSTRUMENTS
EIS
AUDIO PANEL
& CNS
FLIGHT
MANAGEMENT
HAZARD
AVOIDANCE
AFCS
ADDITIONAL
FEATURES
APPENDICESINDEX
Viewing the Telephone Page:
1) Turn the large FMS Knob on the MFD to select the AUX page group.
2) Turn the small FMS Knob to select AUX ‑ TELEPHONE
The PHONE STATUS display, as shown in Figure 8-81, gives a graphical representation of the current disposition
of voice and/or data transmissions. Table 8-5 describes symbology used on PHONE STATUS display.
Figure 8-81 Phone Status Display
Satellite
Signal
Strength
External
Phone
ENABLE/DISABLE THE IRIDIUM TELEPHONE SYSTEM
The Iridium Satellite Telephone System may be turned on or off by using the page menu.
Figure 8-82 Enable Iridium Telephone System
To enable the Iridium telephone system:
1) With the AUX‑TELEPHONE Page displayed, select the MENU Key on the MFD to display the Page Menu.
2) Turn either FMS Knob to place the cursor on ‘Enable Iridium Transmission’.
3) Press the ENT Key.

Garmin G1000 Specifications

General

Display Type	LCD
Primary Flight Display (PFD)	Yes
Multi-Function Display (MFD)	Yes
Terrain Awareness	Yes
Autopilot Integration	Yes
Integrated Flight Deck System	Yes
Weather Radar	Optional
Traffic Advisory System (TAS)	Optional
Terrain Awareness and Warning System (TAWS)	Yes
Resolution	1024 x 768 pixels
Weather Data	Yes
Navigation	Yes
AHRS	Yes
Air Data Computer (ADC)	Yes
Interfaces	ARINC 429, RS-232
Certification	TSO certified
Traffic Information	Optional (requires ADS-B or TCAS)
