When a bearing pointer is displayed, the associated information window is also displayed. The Bearing
Information Windows are displayed at the lower sides of the HSI and give the following information:
• Bearing source (NAV, GPS, ADF)
• Pointer icon (BRG1 = single line, BRG2 = double
line)
• Frequency (ADF)
• Station/waypoint identifier (NAV, GPS)
• GPS-derived great circle distance to bearing
source
When the NAV radio is tuned to an ILS frequency the bearing source and the bearing pointer is removed
from the HSI. When NAV1 or NAV2 is the selected bearing source, the frequency is replaced by the station
identifier when the station is within range. If GPS is the bearing source, the active waypoint identifier is
displayed instead of a frequency.
The bearing pointer is removed from the HSI and NO DATA is displayed in the information window if
the NAV radio is not receiving a VOR station or if GPS is the bearing source and an active waypoint is not
selected.
Selecting bearing display and changing sources:
1) Press the PFD Softkey.
2) Press a BRG Softkey to display the desired bearing pointer and information window with a NAV source.
3) Press the BRG Softkey again to change the bearing source to GPS.
4) Press the BRG Softkey again to change the bearing source to ADF.
5) To remove the bearing pointer and information window, press the BRG Softkey again.
DME INFORMATION WINDOW
The DME Information Window is displayed above the BRG1 Information Window on the 360˚ HSI and in
a box above and along side the Arc HSI. It shows the DME label, tuning mode (NAV1, NAV2, or HOLD),
frequency, and distance. When a signal is invalid, the distance is replaced by –.– – NM Refer to the Audio
Panel and CNS Section for information on tuning the DMEs.
Displaying the DME Information Window:
1) Press the PFD Softkey.
2) Press the DME Softkey to display the DME Information Window.
3) To remove the DME Information Window, press the DME Softkey again.
