SECTION 2 PILOT'S GUIDE
The G5 is an electronic instrument display capable of operating as a standalone flight
display or a fully integrated backup instrument for G3X systems. It features a bright,
sunlight readable, 3.5-inch color display which is sized to fit in a standard 3-1/8-inch
instrument cutout. The G5 additionally provides backup autopilot control allowing
coupled GPS approaches to be flown or continued in the event of primary flight display
loss. In the case of aircraft power loss, the optional battery backup sustains the G5
flight display with up to 4 hours of emergency power.
2.1 BEZEL OVERVIEW
Power On/Off
Backlight
Knob
Ambient
Light Sensor
microSD
™
Card Slot
G5 Bezel Overview
