1.3.2 GENERAL SPECIFICATIONS
See Section 1.2.1.1 for power/current specifications, and Section 1.2.3.1 for
dimension/weight specifications.
1.3.3 INSTALLATION INFORMATION
1.3.3.1 REQUIRED EQUIPMENT
The installation kit (Table 1-5) is required to install the unit, one kit is required for
each G5 installed. The G5 Mounting Ring is included in the installation kit to mount
the G5 to the aircraft panel and to reinforce the panel cutout in thin panel installations.
The installation kit is not included with the G5.
Table 1-5 Contents of the G5 Installation Kit (011-03892-00)
Item Garmin P/N Quantity
Connector Kit, 9 Pin, w/CAN Term 011-03002-00 1
Mounting Ring, G5 115-02251-03 1
Screw, 6-32, 0.500" 211-60207-12 3
Table 1-6 Contents of the Connector Kit (011-03002-00)
Item Garmin P/N Quantity
Sub-Assy, Bkshl w/Hdw, Jackscrew, 9 pin 011-01855-00 1
Sub Assy, CAN Termination Kit 011-02887-00 1
Conn, Rcpt, D-Sub, Crimp Socket, 9 Ckt 330-00625-09 1
Contact, Sckt, D-Sub, Crimp, Size 20, 20-24 AWG 330-00022-02 9
