1.10 PERFORMANCE SPECIFICATIONS/LICENSING/
COMPLIANCE
1.10.1 GPS SPECIFICATIONS
Table 1-22 G5 GPS Specifications
Characteristics Specifications
Acquisition Time
a) Warm Start (position known to 10 nm, time known to 10
minutes, with valid almanac and ephemeris): Less than 5
seconds
b) Cold Start (position known to 300 nm, time known to 10
minutes, with valid almanac): Less than 45 seconds
c) AlwaysLocate™ (with almanac, without initial position or
time): Less than 60 seconds
Update Rate 5/second, continuous
Positional Accuracy <10 meters
1.10.2 ENVIRONMENTAL SPECIFICATIONS
The G5 has an operating temperature range of -20°C to +60°C. The G5 will prevent
operation from the battery when the battery is outside of this temperature range. For
maximum battery longevity, store the within a temperature range of 32˚ to 77˚F (from
0˚ to 25˚C).
