Garmin G5 User's Manual
190-02072-00 Rev. B 103
Pilot's Guide
Installation Manual Pilot's Guide Index
2.6.5 HEADING/GROUND TRACK (PFD PAGE)
NOTE: Heading is displayed if magnetometer data is available from another
ADAHRS via the CAN network. Otherwise, Ground Track is displayed.
A Heading/Ground Track Tape is displayed at the top of the PFD Page and displays
numeric labels every 10°. Major tick marks are at 5° intervals and minor tick marks
at 1° intervals. The current track is represented by a magenta triangle. The Heading/
Ground Track Tape also displays the navigation course.
When displaying the Selected Heading, a light blue bug on the tape corresponds to
the Selected Heading. When displaying Ground Track, a magenta bug is displayed on
the tape. The selected heading is synchronized between the G5 and the other displays
in a G3X/G3X Touch system.
Adjusting the selected heading or ground track:
Use the HDG Knob on the GMC 307.
O
r
1)
Press the Knob to display the Menu.
2)
Select Heading or Track and use the Knob to change the Selected
Heading or Track.
Syncing to the current heading or ground track:
Press the HDG Knob on the GMC 307.
O
r
1)
Press the Knob to display the Menu.
2)
Select Heading or Track and press and hold the Knob to sync the selected
heading or ground track to the current heading or ground track.
