1.4.2 GARMIN ANTENNAS
NOTE: See the G3X Install Manual (190-01115-01) for detailed GPS
antenna installation information. All antenna mounting and unit installation
recommendations applicable to the GDU37X/4XX also apply to the G5.
NOTE: It is the installer’s responsibility to ensure that their choice of antenna
meets FAA standards according to the specific installation.
Table 1-8 Supported Garmin Antennas
Model Part Number Install Manual
Mounting
Configuration
GA26C 011-00149-04 190-00082-00
Flange, Magnetic,
or Suction Cup
Mounts (in-cabin)
GA35 013-00235-0X 190-00848-00
Thru-Mount (tear
drop form factor)
GA36 013-00244-0X 190-00848-00
Thru-Mount (ARINC
743 form factor)
GA56 011-00134-00 190-00094-00
Stud Mount (tear
drop form factor)
Table 1-9 GPS Antenna Minimum Requirements
Characteristics Specifications
Frequency Range 1565 to 1585 MHz
Gain 16 to 25 dB typical, 40 dB max
Noise Figure Less than 4.00 dB
Nominal Output Impedance 50 Ω
Supply Voltage 4.5 to 6.5 VDC
Supply Current up to 60 mA
