1.7.4.10 ARINC 429 CONFIGURATION PAGE
This page allows for configuration of the 2 ARINC 429 output and 4 ARINC 429
input ports on the GAD 29.
Table 1-20 ARINC 429 Outputs
Configuration
Setting
Description
EFIS/Air data
Outputs EFIS and air data labels to a 4XX/5XX series unit. The
transmitted labels are as follows:
203 Pressure Altitude
204 Baro Corrected Altitude
206 Indicated Airspeed
212 Vertical Speed
235 Baro Setting (BCD)
371G Manufacturer ID
377 Equipment ID
Table 1-21 ARINC 429 Inputs
Configuration
Setting
Description
Garmin GPS
(SDI 1)
Receives GPS labels from a GNS 400/500, GNS 480, or GTN
600/700 series unit.
Garmin VOR/ILS
(SDI 1)
Receives VOR/ILS labels from a GNS 400/500,GNS 480, or GTN
600/700 series unit.
1.7.4.11 GPS CONFIGURATION PAGE
This page allows for the configuration and of the G5 GPS. The internal GPS receiver
can be enabled and disabled. The GPS data fields on the PFD can be shown or hidden.
This page also displays the status of the G5's internal GPS receiver. The GPS Status
displays the status of the GPS signal acquisition. If using the internal GPS receiver,
ensure a valid GPS fix can be obtained (indicated by the a green checkmark). The
status of the external GPS antenna (if equipped) is also displayed.
