GHP12InstallationInstructions 23

  
ECU Dimensions (W×H×D) 6
19
/
32
× 4
19
/
32
× 2 in.
(167.6 × 116.8 × 50.8 mm)
Weight 1.5 lb. (0.68 kg)
Temperature
range
from 5°F to 140°F (from -15°C to 60°C)
Case material Fully gasketed, high-impact aluminum
alloy, waterproof to IEC 529 IPX7
standards
Power cable
length
9 ft. (2.7 m)
Input power 11.5–30 Vdc
Fuse 40 A, blade-type
Main power
usage
1 A (not including the drive unit)
CCU Dimensions 3
19
/
32
in. diameter (91.4 mm)
Weight 5.6 oz. (159 g)
Temperature
range
from 5°F to 140°F (from -15°C to 60°C)
Case material Fully gasketed, high-impact aluminum
alloy, waterproof to IEC 529 IPX7
standards
CCU/ECU
interconnect
cable length
16 ft. (5 m)
NMEA 2000
LEN
2 (100 mA)
Alarm Dimensions (L×Diameter)
29
/
32
× 1 in. (23 × 25 mm)
Weight 2.4 oz. (68 g)
Temperature
range
from 5°F to 140°F (from -15°C to 60°C)
Cable length 10 ft. (3.0 m)
GHC 10 Dimensions 4
5
/
16
× 4
3
/
8
× 1
29
/
32
in. (109 × 111 × 48
mm)
Weight 9.6 oz. (272 g)
Cables NMEA 0183 data cable – 6 ft. (1.8 m)
NMEA 2000 drop cable and power cable –
6
1
/
2
ft. (2 m)
Temperature
range
From 5°F to 158°F (from -15°C to 70°C)
Compass-safe
distance
9
1
/
2
in. (241 mm)
Case material Fully gasketed, high-impact aluminum
alloy, waterproof to IEC 529 IPX7
standards
GHC 10 power
usage
2.5 W max
NMEA 2000
input voltage
9–16 Vdc
NMEA 2000
LEN
6 (300 mA)


  
Receive
059392 ISO Acknowledgment
059904 ISO Request
060928 ISO Address Claim
126208 NMEA - Command/Request/Acknowledge
Group Function
126464 Transmit/Receive PGN List Group Function
126996 Product Information
127258 Magnetic Variation
127488 Engine Parameters - Rapid Update
128259 Water Speed
129025 Position - Rapid Update
129026 COG & SOG - Rapid Update
129283 Cross Track Error
129284 Navigation Data
130306 Wind Data
Transmit
059392 ISO Acknowledgment
059904 ISO Request
060928 ISO Address Claim
126208 NMEA - Command/Request/Acknowledge
Group Function
126464 Transmit/Receive PGN List Group Function
126996 Product Information
127245 Rudder Data
127250 Vessel Heading

  
Receive
059392 ISO Acknowledgment
059904 ISO Request
060928 ISO Address Claim
126208 NMEA - Command/Request/Acknowledge
Group Function
126464 Transmit/Receive PGN List Group Function
126996 Product Information
127245 Rudder Data
127250 Vessel Heading
127488 Engine Parameters - Rapid Update
128259 Water Speed
129025 Position - Rapid Update
129029 GNSS Position Data
129283 Cross-Track Error
129284 Navigation Data
129285 Navigation - Route/WP information
130306 Wind Data
130576 Small Craft Status
