If the number of Traffic Advisories on the TIS display decreases and
then increases, a new audio alert is sounded. The TIS audio alert is
also generated whenever TIS service becomes unavailable.
The following TIS audio alerts are available:
• Traffic—TIS traffic alert received.
• Traffic Not Available—TIS service is not available or out of
range.
NOTE: TIS audio alerts can be turned off in the Main Menu
Sound tab.
Traffic Ground Track
Traffic ground track is indicated on the GPSMAP 496 screen by a
“target track vector”, a short line shown in 45-degree increments,
extending in the direction of target movement.
Traffic Warning Window
When a traffic threat is imminent, the Traffic Warning Window is
shown. The Traffic Warning Window shows a small thumbnail map.
Press QUIT to go back to the previous page.
NOTE: The Traffic Warning Window is disabled when the
aircraft ground speed is less than 30 knots or when on the
approach leg of a route.
Traffic Target Track Vector
Traffic Warning Window
GPSMAP 496 Owner’s Manual 151
TIS > TRAFFIC GROUND TRACK AND WARNING WINDOW
