Garmin Rino 130 User Manual

8
Reference
Setting the Channel and Squelch Code
The Rino 130 has a total of 22 channels (not including GMRS repeater channels) and 38
squelch codes to select from using the ‘Channel’ and ‘Code’ fields. Channels 1–14 are for FRS,
15–22 are for GMRS (disabled by default) 15R–22R are for GMRS repeater channels (disabled
by default). To communicate with other Rino and FRS/GMRS users, you must be on the same
channel and squelch code. Garmin Rino units work with 3rd party FRS/GMRS radios, provided
the other radios use standard FRS/GMRS frequencies. A chart of Rino frequencies may be
found in the Appendix.
Squelch codes allow you to hear calls from only specific persons. Thirty-eight (38) Squelch
Codes (called Continuous Tone Coded Squelch System or CTCSS) allow your Rino 130 to
ignore unwanted calls from other persons using the same channel. Simply select the same
squelch code (number) as selected by the other person(s) with which you will communicate.
NOTE: Squelch codes do not cause your conversation to be private. They only allow
you to filter out other users on the same channel, so you only hear the radios you
want to hear. Squelch Codes are not a scrambling system!
Setting the squelch code to 0 (squelch code off) allows you to hear all activity on the se-
lected channel, but you must be set to the same squelch code as the other person(s) to transmit
back. See the Appendix for a table listing all of the 38 Squelch Codes and their frequencies.
As you change the main channels, the Rino 130 remembers the last channel/squelch code
combination that you were using. For example, you may set the unit channel to 5 and squelch
code to 21, then change the main channel to 8 and squelch code to 2. If you change the chan-
nel back to 5, the squelch code changes back to its previous setting of 21. See the Appendix for
more information on FRS/GMRS and its operational aspects.
Radio Page
Select from FRS 1–14,
GMRS 15–22 (with
GMRS enabled), and
15R–22R GMRS
repeater channels (with
GMRS and Repaeter
Channels enabled).

Garmin Rino 130 Specifications

General

Outdoor (hiking, trekking)	Yes
Marine (chartplotters, sounders)	No
Routes quantity	20
Number of waypoints	500
Form factor	Handheld
Grayscale levels	4
Display resolution	160 x 160 pixels
RS-232 ports	1
Internal memory	24 MB
Number of tracklog points	10000
Battery type	AA
Battery life (max)	14 h
Number of batteries supported	3

Weight and Dimensions

Depth	16 mm
Width	58 mm
Height	114 mm
Weight	236 g
