3
Quick Start Steps
1. Power ON.
Press and release the ON / OFF Power button.
2. Set Sensitivity, Threshold and Volume
to preferred levels.
3. Perform Frequency Scan (if needed to
eliminate electrical interference).
Press MENU button until FREQ SCAN is selected,
then presss the MENU plus (+) button to begin
process. Takes approximately 45 seconds.
4. Ground Balance (if needed to eliminate ground
response).
Press and hold GND BAL button while bouncing
coil above the ground until ground response
disappears or becomes as small as possible.
5. Begin scanning.
Lower the searchcoil to about one-half inch (1.25
cm) above the ground and scan the coil left and
right at approximately 3 feet/second (1 meter/
second). The coil must be in motion for target
detection.
This page provides the basic procedures needed to begin detecting with your Garrett Axiom.
FACTORY RESET (if desired)
All settings are saved at Power OFF. Perform a Factory
Reset to return the unit to its factory settings by
holding down the Power button for five (5) seconds
until a double-beep is heard.
Factory settings are:
Sensitivity: 6
Volume: 25
Threshold: 15
Mode: Fine
Frequency: 50
Tone: 50
Audio: 01(VCO)
Ground Balance: 49/49
Wireless: O
Backlight: O
Speed: Medium
Ground Track: O
5
4
1, 2
3
3 feet (1 m) per second at 1/2 inch (1.25 cm) above ground
