System Components 11
A ATX power connector
B SCSI LED connector
C JP10: CPU/Chassis Fan connector
D Front panel control connector
E NLX system board edge connector
F PCI/ISA slot (shared)
G PCI slots (2)
H SW1: Chassis intrusion switch
I CN3: TAD/Speakerphone
J CN4: CD/DVD audio connector
K JP9: Power supply fan connector
L JP7: Wake on LAN connector
M JP8: Ring in connector
