20 Chapter 1
Bluetooth
Audio Codec and Amplifier
LAN Interface
Typical Power Consumption
(watt)
4.0442.85
Weight (without inverter)
255g 225g 255g 255g
Physical Size (mm)
268 (L) x 161.5
(W)
268 x 161.5 x 5 268.0 x 161.5 268.0 x 161.5
Electrical Interface
LVDS LVDS LVDS LVDS
Viewing Angle (degree)
Horizontal (Right) / (Left)
Vertical (Upper) / (Lower)
45/45
20/40
45/45
20/45
45/45
20/40
TBD
Item Specification
Bluetooth Controller Bluetooth module Foxconn Bluetooth BRM 2046 BT2.1 (T60H928.33) F/
W:861
Features • Fully Qualified Bluetooth v2.1 with Class 2 specification RF output
power.
• Enhanced Data Rate (EDR) compliant.
• Full Piconet and Scatternet operation.
• Integrated PIFA Antenna with better RF performance.
• USB 2.0 compliant interface.
• F/W upgradable via Flash downloads.
• Very low power consumption.
• Support Coexistence with Intel WCS (Wireless Coexistence System)
& AFH (Adaptive Frequency Hopping).
Item Specification
Audio
Controller
Realtek ALC269X
Features • Headphone-out with S/PDIF, Line-In and Microphone-In.
• 2 stereo ADCs support 16/20/24-bit PCM format recording simultaneously.
Item Specification
LAN Chipset ATHEROS AR8131L
Package 48pin QFN
Item Specifications
