101 232001840G(08)
Adjustment
Bar
/
Power
Level
(Stamp
Page)
Another important aspect of creating a stamp is setting the slope level of the shoulder. The shoulder
is the section from the "contact section" of the stamp to its base. This function allows you to adjust
the slope for the shoulder sections of your stamp. By sliding the sliders or directly input of power
levels,
you will be able to change the slope of the shoulder.
NOTE
The visual representations of the Pitch and Shoulder Levels in the C180II driver are an
exaggerated representation to allow for easy visual guidance and precise input.
Remember we are working with distances less than 1 mm here.
