GCC Technologies LaserPro C180II - Front View; Top View

232001840G (08)
Please take some time to familiarize yourself with this section regarding the mechanical overview of the
LaserPro C180II. References will be made back to the different parts of the LaserPro C180II in later sections.
3.1 Front View
3.2 Top View
]
Lower Front Door
Emergency Stop
Control Panel
